Spiral-SFG220

spiral-SFG220-50

Being able to move at 2m/second means minimized cycle time, thus decreasing energy costs and minimize the chance of forklift impact, improving productivity no end.

  • Door Type:                   SFG220-50
  • Panel thickness:       50mm
  • Opening Speed:        0.6m/s-2m/s
  • Closing Speed:           0.6m/s
  • Max Door Size:          8000mm *8000mm
  • Window:                        3 triple glass structure
  • Frame Finish:              Roller coating
  • Wind load:                    108 km/h
  • Window:                        Standard, full vision
  • Thermal insulation: 1.25W/(m²K) (5m*5m)
  • Acoustic insulation: 40dB

    what's included

    High Speed Door
    Operator
    Safety edge
    Radar

    DOOR LEAF COLOR

    Safeguard door is providing multiple color options. Doors styles need to conformably buildings. Except for the below most frequently used colors,  Safeguard door also customize colors for satisfy the needs.
